QNAP TS-212P User Manual

71
View system information by the LCD panel
When the LCD panel shows the server name and IP address, press the “Enter” button to
enter the Main Menu. The Main Menu consists of the following items:
1. TCP/IP
2. Physical disk
3. Volume
4. System
5. Shut down
6. Reboot
7. Password
8. Back
1. TCP/IP
The following options are available:
 LAN1 IP Address
 LAN1 Subnet Mask
 LAN1 Gateway
 LAN 1 PRI. DNS
 LAN 1 SEC. DNS
 Enter Network Settings
 Network Settings – DHCP
 Network Settings – Static IP*
 Network Settings – BACK
 Back to Main Menu
* In Network Settings – Static IP, users can configure the IP address, subnet mask,
gateway, and DNS of LAN 1 and LAN 2.
2. Physical disk
The following options are available:
 Disk Info
 Back to Main Menu
The disk info shows the temperature and the capacity of the hard drive.
D
i
s
k
:
1
T
e
m
p
:
5
0
°
C
S
i
z
e
:
2
3
2
G
B

QNAP TS-212P Specifications

General

RAID levels	0, 1, JBOD
RAID support	Yes
Storage drive capacity	8 GB
Storage drive interface	Serial ATA II
Storage drives installed	No
Installed storage drive type	-
Supported storage drive types	HDD
Total installed storage capacity	0 TB
Maximum supported storage capacity	8 TB
Number of storage drives installed	0
Number of storage drives supported	2
Processor family	Marvell
Processor frequency	1.66 GHz
Flash memory	16 MB
Internal memory	512 GB
Internal memory type	DDR3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Product color	White
Type	NAS
Power consumption (sleep)	6 W
Power consumption (typical)	13 W

Weight and Dimensions

Depth	218.4 mm
Width	85 mm
Height	165.5 mm
Weight	910 g
Package weight	2200 g
