QNAP TS-653A User Manual

73
7. Password
The default password of the LCD panel is blank. Enter this option to change the
password of the LCD panel. Select “Yes” to continue.
C
h
a
n
g
e
P
a
s
s
w
o
r
d
Y
e
s
→
N
o
Enter a password of maximum 8 numeric characters (0-9). When the cursor moves to
“OK”, press the “Enter” button. Verify the password to confirm the changes.
N
e
w
P
a
s
s
w
o
r
d
:
O
K
8. Back
Select this option to return to the main menu.
System Messages
When the NAS encounters system error, an error message will be shown on the LCD panel.
Press the “Enter” button to view the message. Press the “Enter” button again to view the
next message.
S
y
s
t
e
m
E
r
r
o
r
!
P
l
s
.
C
h
e
c
k
L
o
g
s
System Message
Description
Sys. Fan Failed
The system fan fails
Sys. Overheat
The system overheats
HDD Overheat
The hard drive overheats
CPU Overheat
The CPU overheats
Network Lost
Both LAN 1 and LAN 2 are disconnected in failover or
load-balancing mode
LAN1 Lost
LAN 1 is disconnected
LAN2 Lost
LAN 2 is disconnected
HDD Failure
The hard drive fails
Vol1 Full
The volume is full
HDD Ejected
The hard drive is ejected
Vol1 Degraded
The volume is in degraded mode
Vol1 Unmounted
The volume is unmounted
Vol1 Nonactivate
The volume is not activated

QNAP TS-653A Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
Storage drive size	2.5/3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4
Storage drive interface	Serial ATA III
Storage drives installed	No
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	6
Operating system version	4.2
Operating system installed	QNAP Turbo System
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 8, Windows 8 x64
Type	NAS
Noise level	21 dB
Device class	Small & Medium Business
Share folder	CIFS/SMB
Backup features	Cloud, iSCSI LUN
Browser supported	Microsoft Internet Explorer 10+, Mozilla Firefox 8+, Apple Safari 4+, Google Chrome
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH
L2 cache	2 MB
Stepping	C0
Tjunction	90 °C
Processor code	SR29F
Processor cores	4
Processor model	N3150
System bus rate	5 GT/s
Processor family	Intel® Celeron®
Processor series	Intel Celeron N3000 series
Processor socket	BGA 1170
Processor codename	Braswell
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	25 x 27 mm
CPU configuration (max)	1
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.08 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 4x1
Thermal Design Power (TDP)	6 W
Scenario Design Power (SDP)	4 W
On-board graphics card model	Intel® HD Graphics
Maximum internal memory supported by processor	8 GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Chassis type	Tower
Cooling type	Active
Display type	LCD
Fan diameter	90 mm
Product color	Black
LED indicators	HDD, Status, USB
Number of fans	2 fan(s)
Housing material	-
Cable lock slot type	Kensington
Flash memory	512 MB
Memory clock speed	1600 MHz
Internal memory type	DDR3L
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC
Fan voltage	12 V
Output current	5 A
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Power supply location	Built-in
Power consumption (off)	1.7 W
Power consumption (sleep)	32.02 W
Power consumption (typical)	51.16 W
Power supply unit (PSU) capacity	240 W
Cables included	AC, LAN (RJ-45)
Number of screws	42
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Processor ARK ID	87258
Number of execution units	12
Memory types supported by processor	DDR3L-SDRAM
Memory channels supported by processor	Dual
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00
On-board graphics card base frequency	320 MHz
On-board graphics card burst frequency	640 MHz
Number of displays supported (on-board graphics)	3

Weight and Dimensions

Depth	235 mm
Width	257 mm
Height	175 mm
Weight	5200 g
Package weight	6500 g
