This NUMBER parameter allows you to change the Sidetone frequency if you wish. Sidetone is
the audio tone which is generated by the microcontroller on key-down and injected into the audio
signal path. Sidetone is ONLY an operator convenience to let you hear your keyed signal, and has
no impact at all on the transmitted RF amplitude or frequency.
Sidetone vol
099
You can use this parameter to reduce the volume of the sidetone audio. See full description in the
“Audio” menu above, where this parameter also appears.
Sidetone abs/rel
Relative
Controls whether the sidetone is applied absolutely or relative to the main volume control level.
See full description in the “Audio” menu above, where this parameter also appears.
Strght mode
Both
Available settings are “tip”, “ring” and “both”. This controls the action of a key plugged into the key
jack during Straight Key mode only. It is inherited from the QCX-series transceivers; if a 3.5mm
mono plug was used with the QCX+, the longer ground barrel shorted the ring to ground causing
continuous keying. This configuration menu is the solution to that problem. If you are using a mono
3.5mm plug with your straight key, then set this configuration to “Tip” so that the ring connection
(available only on stereo plugs) is ignored.
GPS protection
ENABLE
If QMX detects a GPS receiver has been plugged into the paddle port, it will automatically set up a
temporary “Practice mode” (if practice mode is not already enabled) so that the radio is not
continuously keyed by the incoming GPS serial data and 1pps. A ‘G’ character appears in the
display to the right of the frequency on the top row (where the ‘P’ would be shown in Practice
mode).
QMX operang manual; rmware 1_00_012 24
