QRP Labs QMX User Manual

Horizontal size (Hz):
The available horizontal screen size (selected by the left/right arrow keys) are chosen to cleanly fit
the 80 columns display width.
Screen
width (Hz)
Horizontal
Div (Hz)
12 1.5
20 2.5
40 0.5
80 1
160 2
320 4
Demonstration of sliding frequency changes
A fun and useful demonstration of the capabilities of QMX and the Input Analysis application, is to
investigate the FT8 tone change transition. We know according to the WSJT-X documentation that
to avoid splatter onto adjacent frequencies, WSJT-X makes a smooth transition between one tone
symbol and the next. It’s nice to be able to check this using the Input Analysis screen.
QMX operang manual; rmware 1_00_012 80
