Preset Defaults
The following settings apply to all factory presets.
Sensitivity: 1.2V (+4dBu)
Crossover: POLARITY +
EQ Band 1: GAIN 0.0 dB, FREQUENCY 100 Hz, BANDWIDTH 1.0 OCT
EQ Band 2: GAIN 0.0 dB, FREQUENCY 500 Hz, BANDWIDTH 1.0 OCT
EQ Band 3: GAIN 0.0 dB, FREQUENCY 1000 Hz, BANDWIDTH 1.0 OCT
EQ Band 4: GAIN 0.0, dB FREQUENCY 5000 Hz, BANDWIDTH 1.0 OCT
Delay: 0.00 MS, M, FT (milliseconds, meters, and feet)
Limiter: TYPE MEDIUM, POWER 800 W (400 W), IMP 8Ω
Table 5 lists the unique factory default settings for each preset.
Preset DSP Type Loudspeaker Type High-Pass Filter Low-Pass Filter Configuration
P1 Stereo Full Range Satellite 20 Hz Bypass
2
ST
DSP
B
1
A
P1–P4: ST SAT
P2 Stereo Full Range Satellite 80 Hz Bypass
P3 Stereo Full Range Satellite 90 Hz Bypass
P4 Stereo Full Range Satellite 100 Hz Bypass
P5 Stereo Subwoofer 20 Hz 80 Hz
P5–P7: ST SUB
2
ST
DSP
B
1
A
P6 Stereo Subwoofer 20 Hz 90 Hz
P7 Stereo Subwoofer 20 Hz 100 Hz
P8
DSP A
DSP B
Monitor
60 Hz
60 Hz
Bypass
Bypass
P8–P10
: MONITORS
2
DSP
B
1
A
DSP
P9
DSP A
DSP B
Monitor
80 Hz
80 Hz
Bypass
Bypass
P10
DSP A
DSP B
Monitor
100 Hz
100 Hz
Bypass
Bypass
P11
DSP A
DSP B
Subwoofer
Full Range Satellite
20 Hz
80 Hz
80 Hz
Bypass
P11–P13: SUB SAT
2
DSP
B
1
A
DSP
P12
DSP A
DSP B
Subwoofer
Full Range Satellite
20 Hz
90 Hz
90 Hz
Bypass
P13
DSP A
DSP B
Subwoofer
Full Range Satellite
20 Hz
100 Hz
100 Hz
Bypass
P14
DSP A
DSP B
Biamp
20 Hz
1000 Hz
1000 Hz
Bypass
P14–P18: BIAMP
2
DSP
B
1
A
DSP
P15
DSP A
DSP B
Biamp
20 Hz
1100 Hz
1100 Hz
Bypass
P16
DSP A
DSP B
Biamp
20 Hz
1200
1200 Hz
Bypass
P17
DSP A
DSP B
Biamp
20 Hz
1300 Hz
1300 Hz
Bypass
P18
DSP A
DSP B
Biamp
20 Hz
1500 Hz
1500 Hz
Bypass
P19 Stereo Mono Full Range Satellites 50 Hz Bypass
ST
DSP
2
B
1
A
P19–P20
: MONO SATS
P20 Stereo Mono Full Range Satellites 100 Hz Bypass
— Table 5 —
