QSC K8.2 User Manual

EN
5 (DRAFT 2017/05/02)
TD-000523-00-01-C
Features
K8.2
1. ABS enclosure
2. Steel grille
3. Front power LED
4. Cast aluminum handle
5. Power module
6. M10 installation points
7. M5 yoke-attachment points
8. 7.5° Downward-tilt pole socket
9. Vertical pole socket
10. Pull-back ring
11. Slip-resistant feet for floor monitor applications
12. Angled back for use as a stage monitor
K10.2
1. ABS enclosure
2. Steel grille
3. Front power LED
4. Cast aluminum handles
5. Power module
6. M10 installation points
7. M5 yoke attachment points
8. 7.5° Downward-tilt pole socket
9. Vertical pole socket
10. Pull-back ring
11. Slip-resistant feet
12. Angled back for use as a stage monitor
— Figure 1 —
K.2 Series
1
4
7
5
6
7
9
8
3
1
7
4
10
10
11
11
6
1111
12
11
2
— Figure 2 —
K.2 Series
1
4
7
5
6
7
9
8
3
1
7
4
10
10
11
11
6
1111
4
12
2
7

QSC K8.2 Specifications

General

Amplifier class	D
Recommended amplifier power (max)	1800 W
Recommended amplifier power (min)	225 W
Amplifier/receiver input interface type	3.5 mm jack, XLR
Certification	CE, WEEE, UL, China RoHS, RoHS II, FCC B
Product color	Black
LED indicators	Yes
RMS rated power	- W
Housing material	Acrylonitrile butadiene styrene (ABS)
Recommended usage	Universal
Audio output channels	1.0 channels
Multi-Room Streaming (MRS) support	-
Speaker type	2-way
Number of drivers	2
Speaker placement	Floor
AirPlay	No
Display	1.75\
Transducer material	Titan
Frequency range	55 - 20000 Hz
Connectivity technology	Wired
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Package weight	14400 g
Speaker interface type	XLR

Weight and Dimensions

Depth	269 mm
Width	280 mm
Height	449 mm
Weight	12200 g
