23
Dimensions
KLA12
KLA181
— Figure 39 —
TopFrontSide
16.6 in (422 mm)
15.0 in (381 mm)
23.4 in (594 mm)
16.6 in (422 mm)
— Figure 40 —
25.7 in (653 mm)
Side
25.7 in (653 mm)
Top
Side with Optional Casters
30.0 in (762 mm)
21.6 in (547 mm)
Front
23.4 in (594 mm)
