QSC MP-M80 - MP Manage − Paging

65
TD-001578-01-C
MP Manage − Paging
These screens are used to record, preview, and send pages over the
MP-M system.
Make sure the tablet or smartphone is set up so that the MP-Manager
app has access to the device’s microphone.
Make sure that the Zones to receive the pages are set up so that WiFi
Paging is a Priority Source to the Zones.
1. Record Page – Touch to start recording the page.
2. The Recording screen displays.
3. Speak the message. The progress bar moves to indicate
recording is taking place.
4. Stop / Exit Recording – Touch to stop recording.
5. Preview Page – Touch to listen to the page.
6. Progress bar – Indicates progress of the recorded page. The
audio plays back through the device.
7. Stop Playback / Exit – Touch to stop playback and exit the
playback screen
8. Send Page – Touch to send the page over the system.
9. Paging System In Use – Displays to indicate the page is being
played back over the designated zones.
Touch
Paging
3
4
1
9
6
8
5
2
7
