QSC PLD4/2

13
CH CH
TD-000368-05-A
—图17—
F5: AB C+D
F5: AB C+D
AB Parallel
C+D Bridged
1
AB
3
C+D
The following are electrically
the same point
A (1+) and B (1+)
A (1-) and B (1-)
X (2+) and Y (1+)
X (2-) and Y (1-)
A B X
2+
2-
C D Y
1+
1-
1-
1+
1+
1-
= Subwoofer
= Mid Range
Optional
—图18—
F4: AB CD
F4: AB CD
AB Parallel
CD Parallel
The following are electrically
the same point
A (1+) and B (1+)
A (1-) and B (1-)
C (1+) and D (1+)
C (1-) and D (1-)
= Subwoofer
= Mid Range
1
AB
3
CD
Optional
A
C
B
D
X
Y
1+
1-
1+
1-
1+
1-
1+
1-
—图19—
F7: ABC D
F7: ABC D
1
ABC
4
D
ABC Parallel
D Single
The following are electrically
the same point
A (1+), B (1+), and C (1+)
A (1-), B (1-), and C (1-)
= Subwoofer
= High Range
Optional
A B X
1+
1-
C D Y
1+
1-
1+
1-
1+
1-
3-通道配置
—图20—
F3: Config - A+B C D
F3: Config - A+B C D
A+B Bridged
C Single
D Single
1
A+B
3
C
4
D
= Subwoofer
= Mid Range
A B X
C D Y
1+
1-
= High Range
1+
1-
1+
1-
AB 并联
C+D 桥接
AB 并联
并联
ABC 并联
D 单独
A+B 桥接
C 单独
D 单独
以下在相同的电力点上
A (1+) 和 B (1+)
A (1-) 和 B (1-)
X (2+) 和 Y (1+)
X (2-) 和 Y (1-)
以下在相同的电力点上
A (1+) 和 B (1+)
A (1-) 和 B (1-)
C (1+) 和 D (1+)
C (1-) 和 D (1-)
以下在相同的电力点上
A (1+)、B (1+) 和 C (1+)
A (1-)、B (1-) 和 C (1-)
= 亚低音扬声器
= 亚低音扬声器
= 亚低音扬声器
= 亚低音扬声器
= 中幅
= 中幅
= 高幅
= 中幅
= 高幅
可选
可选
可选
