QSC PLX 1104 - Appendix A: Speakon Wiring Reference; Two-Wire Single-Channel Speakon; Four-Wire Two-Channel Speakon; Bridge Mode Speakon Connection

14
Appendix A: Speakon Wiring Reference
Amplifier connection
To loudspeaker
Two-wire, single-channel connection
Four-wire, two-channel connection
Bridge mode connection
NOTE! Ensure proper polarity when
connecting bridge mode output!
