QSee QT534 User Manual

140 141
Parameter QT5440 QT5516 QT5616
COMPRESSION Compression
Format
Standard H.264 Baseline
VIDEO Video In Composite 1.0V
p-p/75Ω,
BNC x 4
Composite 1.0V p-p/75Ω,
BNC x 16
Video Out COMPOSITE 1.0V p-p/75Ω, BNC x 2, VGA x 1, HDMI
x 1
VGA Resolution 1280x1024, 1024x768, 800x600, HDMI
Record
Resolution
NTSC:
352x240,
704x480
960x480
PAL:
352x288,
704x576
960x576
NTSC: 352x240,
704x480
PAL: 352x288,
704x576
NTSC:
352x240,
704x480
960x480 (960H)
PAL: 352x288,
704x576
960x576 (960H)
Display Frame
Rate
(per camera)
704x480 at 30FPS
Record Frame
Rate
(per camera)
NTSC:
960H & D1 30
FPS
CIF 30FPS
PAL:
960H & D1
25FPS CIF
25FPS
NTSC: 30FPS PAL: 25FPS
AUDIO Audio Input -8dB~ 22k,
RCA X2
-8dB~ 22k, RCA X4
Audio Output -8dB~92dB, RCA X1
ALARM Alarm Input None NO or NC 16CH
Alarm Output None 1CH
STORAGE Record Mode Manual/Sensor/Timer/Motion Detection
Multi-Function Multiplex
INTERFACE Network
Interface
RJ45 (LAN, Internet)
Communication
Interface
RS485,
USB 2.0 x 2 (One for Backup, One for USB Mouse)
CONTROLS PTZ Control Yes
Remote Control Yes
DISK INFO Disk Type SATA x 1 (up to
2TB each)
SATA x 1 (up to 3TB each)
OTHER INFO Voltage 12V2A 12V3A
Optimal
Temperature
50°F to 104°F 10°C to 40°C
10% to 90% Humidity
Power Use
w/o Hard Drive
5W 18W
Parameter QT5032 QT5132 QT5140
COMPRESSION Compression
Format
Standard H.264 Baseline
VIDEO Video In Composite 1.0V
p-p/75Ω,
BNC x 32
Composite 1.0V
p-p/75Ω,
BNC x 32
Composite 1.0V
p-p/75Ω,
BNC x 4
Video Out COMPOSITE 1.0V p-p/75Ω, BNC x 1, VGA x 1, HDMI
x 1
VGA Resolution 1280x1024, 1024x768, 800x600, HDMI
Record
Resolution
NTSC:
352x240,
704x480
960x480 (960H)
PAL: 352x288,
704x576
960x576 (960H)
NTSC: 352x240, 704x480
PAL: 352x288, 704x576
Display Frame
Rate
(per camera)
704x480 at 30FPS
Record Frame
Rate
(per camera)
NTSC:
960H & D1 30
FPS
CIF 30FPS
PAL:
960H & D1
25FPS CIF
25FPS
NTSC:
D1 30 FPS
CIF
30FPS
PAL:
D1 25FPS CIF
25FPS
NTSC:
960H & D1 30
FPS
CIF 30FPS
PAL:
960H & D1
25FPS CIF
25FPS
AUDIO Audio Input -8dB~ 22k,
RCA X16
-8dB~ 22k, RCA
X4
-8dB~ 22k,
RCA X2
Audio Output -8dB~92dB, RCA X1
ALARM Alarm Input NO or NC 16CH None
Alarm Output 4CH 1CH None
STORAGE Record Mode Manual/Sensor/Timer/Motion Detection
Multi-Function Multiplex
INTERFACE Network
Interface
RJ45 (LAN, Internet)
Communication
Interface
eSATA x2
RS485,
USB 2.0 x 2
(One for
Backup, One
for USB Mouse)
RS485,
USB 2.0 x 2 (One for Backup, One
for USB Mouse)
CONTROLS PTZ Control Yes
Remote Control Yes
DISK INFO Disk Type SATA x 8 (up to
3TB each)
SATA x 2 (up to
3TB each)
SATA x 1 (up to
2TB each)
OTHER INFO Voltage 110/230V 12V4A 12V2A
Optimal
Temperature
50°F to 104°F 10°C to 40°C
10% to 90% Humidity
Power Use
w/o Hard Drive
42W
40W 5W
