Parameter QT5680 QQT5682
COMPRESSION Compression
Format
Standard H.264 Baseline
VIDEO Video In Composite 1.0V p-p/75Ω,
BNC x 8
Video Out COMPOSITE 1.0V p-p/75Ω, BNC x 1, VGA x 1, HDMI
x 1
VGA Resolution 1280x1024, 1024x768, 800x600, HDMI
Record
Resolution
NTSC:
352x240,
704x480
PAL:
352x288,
704x576
NTSC:
352x240,
704x480
976x494
PAL:
352x288,
704x576
976x582
Display Frame
Rate
(per camera)
704x480 at 30FPS
Record Frame
Rate
(per camera)
NTSC:
D1 30 FPS
CIF 30FPS
PAL:
D1 25FPS
CIF 25FPS
NTSC:
960H 30 FPS
D1 30 FPS
CIF 30FPS
PAL:
960H 30 FPS
D1 25FPS
CIF 25FPS
AUDIO Audio Input -8dB~ 22k, RCA X2
Audio Output -8dB~92dB, RCA X1
ALARM Alarm Input None
Alarm Output None
STORAGE Record Mode Manual/Sensor/Timer/Motion Detection
Multi-Function Multiplex
INTERFACE Network
Interface
RJ45 (LAN, Internet)
Communication
Interface
RS485,
USB 2.0 x 2 (One for Backup, One
for USB Mouse)
CONTROLS PTZ Control Yes
Remote Control Yes
DISK INFO Disk Type SATA x 1 (up to 3TB each)
OTHER INFO Voltage 12V2A 12V2A
Optimal
Temperature
50°F to 104°F 10°C to 40°C
10% to 90% Humidity
Power Use
w/o Hard Drive
5W 5W
Parameter QT5716 QT534
COMPRESSION Compression
Format
Standard H.264 Baseline
VIDEO Video In Composite 1.0V
p-p/75Ω,
BNC x 16
Composite 1.0V
p-p/75Ω,
BNC x 4
Video Out COMPOSITE 1.0V p-p/75Ω, BNC x 1, VGA x 1, HDMI
x 1
VGA Resolution 1280x1024, 1024x768, 800x600, HDMI
Record
Resolution
NTSC: 352x240, 704x480
PAL: 352x288, 704x576
Display Frame
Rate
(per camera)
704x480 at 30FPS
Record Frame
Rate
(per camera)
NTSC:
D1 30 FPS
CIF 30FPS
PAL:
D1 25FPS CIF 25FPS
AUDIO Audio Input -8dB~ 22k,
RCA X2
-8dB~ 22k, RCA
X1
Audio Output -8dB~92dB, RCA X1
ALARM Alarm Input None
Alarm Output None
STORAGE Record Mode Manual/Sensor/Timer/Motion Detection
Multi-Function Multiplex
INTERFACE Network
Interface
RJ45 (LAN, Internet)
Communication
Interface
RS485,
USB 2.0 x
2 (One for
Backup, One
for USB Mouse)
RS485,
USB 2.0 x 2
(One for Backup,
One for USB
Mouse)
CONTROLS PTZ Control Yes No
Remote Control Yes No
DISK INFO Disk Type SATA x 1 (up to 3TB each)
OTHER INFO Voltage 12V3A 12V2A
Optimal
Temperature
50°F to 104°F 10°C to 40°C
10% to 90% Humidity
Power Use
w/o Hard Drive
8W 5W
