3. SPECIFICATIONS

Power Supply

Input Voltage 100 VAC – 132 VAC @ 50/60 Hz 198 VAC – 264 VAC @ 50/60 Hz

Rated Current 10 Amps max. 6.3 Amps max.

Fuse Rating 12 Amps Slow Blow 6.3 Amps Slow Blow

Weight 16 lbs. (6.8 Kg)

Dimensions

8"W x 15.25"L x 8.5"H

203 mm x 387 mm x 216 mm

Output Voltage 1000 VRMS (max.)

Output Frequency 20 KHz

Converter

Weight 2 lbs. (900 g)

Dimensions

7.25" L x 2.5" Dia.

(183 mm x 63.5 mm)

Materials Aluminum Alloy

Standard ½” Horn

Weight 0.75 lbs. (340 g)

Dimensions

5.375" L x .5" Dia.

(136 mm x 13 mm)

Materials Titanium Alloy
