Qtx PAL12 - Specifications

PAL12 PAL15 User Manual
Specifications
Model
PAL12
PAL15
Power supply
230Vac, 50Hz (IEC), 12Vdc or internal battery
Power output
80W
Main driver
300mmØ (12“)
380mmØ (15“)
HF driver: type
Compression driver
Impedance: Speaker
4 Ohms
Frequency response
55Hz - 16kHz
50Hz - 16kHz
Battery type
12V 4.5Ah sealed lead-acid
12V 7Ah sealed lead-acid
Battery life
Up to 6 hours (3 hours with LEDs on)
Recharge time
8 hours
Inputs
Wired mic (jack), Guitar (jack), Aux (RCA & mini jack)
Audio source
USB/SD player with FM tuner & Bluetooth
Controls
VHF A+B mic, Wired Mic, Guitar, Media, Bass, Treble, Echo
Line output
RCA
Bluetooth version
2.3
SPL @ 1W/1m
94dB
96dB
Wireless mic. frequencies
174.1MHz + 175.0MHz
Dimensions
585 x 375 x 305mm
690 x 450 x 370mm
Weight
9.26kg
12.74kg
