SPECIFICATIONS
(All measurement made with 230V supply)
D/A Converter ESS ES9018 32bit DAC
Output Level (1kHz) 0 - 2.6 Vrms (PRE Outputs)
0 – 5.2 Vrms (Balanced Outputs)
L/R Channel Difference ±0.02dB (1kHz)
Frequency Response -0.2dB(20Hz-20kHz, 1kHz)
Total Harmonic Distortion <0.001% (20Hz-20kHz)
Linearity ±0.01dB (20Hz-20kHz)
Signal to Noise Ratio(S/N) >110dB (1kHz)
>118dB (A Weighted, 1kHz)
Channel Separation >100dB (1kHz)
USB Input 1 × USB (Support HID)
USB Input Sampling Rates 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 384kHz
USB DSD DSD64, DSD128, DSD256
Digital Audio Inputs 2 × Optical TOSlink
2 × RCA(DIG1, DIG2)
Digital Audio Outputs 1 × Optical TOSlink
1 ×RCA(DIG)
Digital Inputs & outputs Sampling Rates 44.1 - 192kHz
Analogue Inputs 2 × RCA(AUX1, AUX2)
Power Requirement 240V~50-60Hz
230V~50-60Hz
115V~50-60Hz
100V~50-60Hz
Dimension(mm) (W x D x H) 320x320x105mm
Carton Size(mm) (W xD x H) 465x465x220mm
Weight 8.5Kg (Net)
10.5Kg (Gross)
