QUAD Artera Stereo - SPECIFICATIONS; Technical Performance Data

6
SPECIFICATIONS
(Measurement made with 230V supply, one channel driven and applied to either channel)
Rated Output Power 140W 8 ohm (<1% THD,1kHz)
Total Harmonic Distortion
<0.003% (100W, 1kHz)
<0.03% (100W, 20Hz-20kHz)
Frequency Response
-0.5dB (20Hz-20kHz, ref. 1kHz)
-3dB (20Hz-70kHz, ref. 1kHz)
Input Sensitivity 980mV(RCA line in)
Input Impedance
10kohm (Balanced)
15kohm (Unbalanced)
Signal to Noise Ration(S/N) 115dB (A weighted, ref. 140W)
Power Requirement
240V~50-60Hz
230V~50-60Hz
115V~50-60Hz
100V~50-60Hz
Maximum Power Consumption 750W
Standby Power Consumption <0.5W
Dimensions(mm)(W x H x D) 320 X 158 X 338
Carton Size(mm)(W x H x D) 465 x 260 x 465
Weight
15kg (Net)
17kg (Gross)
