CONTROLS AND FUNCTIONS
Remote
Input
Bluetooth Antenna
Analog
Inputs
Pre Output L/R Amplifier
Output
Digital
Outputs
Digital
Inputs
PC USB
Inputs
Mains
Fuseholder
Mains
Switch
Mains
Input
Update
Ground
Headphone
Output
Bluetooth
BUTTON/LED
PC USB
BUTTON/LED
OPT1&2
BUTTON/LED
COAX
BUTTON/LED
Analog 1&2
BUTTON/LED
Volume
Control
Standby
BUTTON/LED
PHONO BUTTON/LED
* Vena II with wooden chassis does not require Bluetooth antenna
