2 7044-225I August 13, 2018
3100 Insert ACC
1 Important Safety Information ............. 3
A. Insert Certication ...........................3
B. BTU & Efciency Specications ................3
C. Mobile Home Approved.......................4
D. Glass Specications .........................4
E. Non-Combustible Materials ....................4
F. Combustible Materials ........................4
G. Sleeping Room .............................4
H. California - Prop65 ..........................4
2 Getting Started .................................... 5
A. Design and Installation Considerations ...........5
B. Draft......................................5
C. Negative Pressure...........................6
D. Tools And Supplies Needed ...................6
E. Inspection of Appliance and Components .........6
F. Install Checklist .............................7
3 Dimensions and Clearances .............. 8
A. Appliance Dimensions ........................8
B. Clearances to Combustibles ...................9
C. Calculating Alternate Floor Protection...........10
4 Chimney Systems ............................. 11
A. Locating Your Appliance & Chimney ............11
B. Chimney Termination Requirements ............12
C. 2-10-3 Rule ..............................12
D. Venting Systems ...........................13
E. Inspections ...............................13
F. Chimney Height / Rise and Run................13
G. Securing Chimney Components ...............13
H. Larger Chimneys...........................13
I. Masonry Chimney...........................14
J. Metal Heat Circulating Masonry................15
K. Prefabricated Metal Chimney .................15
L. Ovalizing Round Stainless Steel Liners..........16
M. Altering The Fireplace.......................16
N. Zero-Clearance Fireplace ....................16
5 Appliance Set-Up .............................. 17
A. Outside Air Kit Installation ....................17
B. Disassemble Firebox & Outer Can .............18
C. Securing Stove Pipe/Liner to Flue Collar ........18
D. Optional Offset Adapter Installation.............18
E. Installing Outer Can & Leveling Bolts ...........19
F. Surround & Trim Kit Installation ................20
G. Installing Firebox into Outer Can ..............20
H. Securing Appliance to Stove Pipe/Liner .........21
I. Leveling Legs ..............................21
J. Snap Disc and Side Panel Installation ...........21
K. Blower Installation ..........................21
L. Blower Cord Installation on Left Side............22
M. Zero Clearance Adjustable Trim Support ........23
6 Mobile Home Installation .................. 24
7 Reference Materials .......................... 25
A. Service and Maintenance Log.................25
B. Accessories List............................27
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Quadra-Fire is a registered trademark of Hearth & Home Technologies.
