5700 ACT Wood Stove
FIGURE 24C - Bafe with ceramic blanket on top.
Allen wrench
on retainer bolt
First tube has larger holes
FIGURE 24B - Allen wrench on retainer bolt.
DOOR HANDLE ASSEMBLY
See Figure 24B.
NOTE: When replacing the secondary tubes, be sure the tube with the larger holes is placed in the front or your stove will not
operate properly.
See Figure 24C.
BAFFLE REMOVAL AND INSTALLATION
CAUTION! DO NOT OVERTIGHTEN LOCKNUT. DOOR
HANDLE NEEDS TO MOVE SMOOTHLY.
See Figure
24.
SPRING HANDLE WARNING!
3” (76mm) clearance is required from bend in
Door Handle Rod to end of the Spring Handle.
If installed within that 3” (76mm) area, Spring
Handle will get hot and may cause injury.
NOTE:
SEE PAGE 18 FOR OPERATING INSTRUCTIONS
FIGURE 24A
Locknut
Door Cross Section
(example)
Latch Cam
Spacing
Washers
Square Key
Door Handle
Spring
Handle
3" (76mm) clearance
required from bend in Door
Handle Rod to end of Spring
Handle.
Secondary
Latch
To Next Page
