Quadra-Fire CAB50-C - 3 Dimensions and Clearances; Appliance Dimensions

8 09/207074-803C
3 Dimensions and Clearances
A. Appliance Dimensions
Figure 8.3 - Front View
Figure 8.1 - Top View
Figure 8.2 - Side View
10 in
(252mm)
10 in
(252mm)
2-1/4 in
(59mm)
23-3/4 in
(603mm)
36-1/2 in
(927mm)
9-1/2 in
(243mm)
24-1/2 in (622mm)
12-1/2 in
(318mm)
25-7/8 in (657mm)
26-5/8 in (677mm)
26-3/4 in (681mm)
9-1/8 in
(231mm)
