Technical data
Voltage: 220-240 V ~ 50 Hz
Power input: 1000W watts
Motor speed: 3350min
-1
Cutting width: 32cm
Cutting height adjustment: 20, 40, 60 mm
Volume of grass collector: 33 liters
LpA sound pressure level: 73.5dB(A)
LWA sound power level: 96 dB(A)
Vibration at the handlebars ahv: < 2.03m/s2
Protection class II
Before starting the equipment
The push handles and the grass collector must be fully assembled
before using the lawn mower. Follow the operating instructions
step-by-step and use the pictures provided as a visual guide to
assemble these parts.
Bottom handle support assembly
B
1. Insert the each lower bar (3) into the slot in the housing (6)
2. Use the screws (13) provided to lock each bar into position
C
3. Fix the top curved handle (1) section to the lower bars (3). Use the
bolts (14) and wing nuts (14) provided. There are two possible height
positions. Chose the one most suitable to the operator’s height.
4. Clip the cable to the handle bar with the cable clamp (8) provided.
When the two wing nuts are loosened, the handle can be folded (Fig.I ) for
easy storage. Ensure the power cable is not caught between the folding
sections.
Grass collector assembly
D
Clip the two sections (16) of the grass collector together
Clip the handle into the top of the grass collector.
