Maintenance
XC92YC spark plug 974225 blade nut
974903 collection bag 466018 knob
974213 blade 974008 mulching plug
974926 battery 974927 charger
Maintenance
Spare blades and other parts can be purchased in store or via www.gardenservicecentre.co.uk
Replacing Cutting Blade (continued)
List of Consumable Qualcast Parts
Parts can be ordered via www.gardenservicecentre.co.uk
1. Tip the machine slightly towards the oil ller pipe and reach under the deck.
2. Hold the blade and unscrew the blade bolt counterclockwise using a spanner wrench. Remove
the washer and the blade.
3. Inspect the blade adaptor on any signs of damage.
4. Fit a new blade, locate the blade on the two studs on the blade ange and then replace the
washer and bolts.
5. Check the washer is still slightly domed to keep the pressure on the bold to stop it unwinding,
keeping the blade rmly secure. Then replace the washer (right way around!) and bolts.
6. Make sure the blade is correctly located, and then rmly tighten the bolt. Do not over tighten. The
up turn of the blade must project into the motor compartment.
NOTE!
- The blade carrier is designed to break under heavy blade impact to protect the machine. if this
happens also replace the blade carrier. This can be purchased from www.gardenservicecentre.co.uk
- If you are unsure about performing this operation call our helpline or go to an authorised dealer to
change the blade for you. .
Troubleshooting
General Troubleshooting
WARNING!
- Always switch off the engine and pull the ignition cable before starting any inspection or
adjustment work.
- If, after making an adjustment or repair to the engine, you let it run for a few minutes, remember
that the exhaust and other parts will get hot.
Fault Possible Cause Solution
Loud while running,
machine vibrates heavily
- Screws are loose
- Blade fasteners are loose
- Blade is unbalanced
- Check screws
- Check blade fasteners
- Replace blade
Engine does not start - start/stop bar not pressed
- Spark plug is defective
- Fuel tank is empty
- Engine may be ooded
- Battery is empty.
- Press start/stop bar
- Replace spark plug
- Rell with fuel
- Remove plug and dry, see
page 11 Charge the battery.
Engine runs unsteadily - Air lter is soiled
- Spark plug is soiled
- Clean the air lter
- Clean the spark plug
Uneven mowing results - Blade is blunt
- Cutting height is too low
- Sharpen the blade
- Set correct height
Unsatisfactory grass
collection
- Cutting height is too low
- Blade is worn
- grass bag is clogged
- Set correct height
- Replace the blade
- Empty the grass bag
The following table provides solutions to common problems encountered with the lawnmower.
