Chapter 1
Product Specifications
Dimensions
220 x 153.3 x 38 mm (W x D x H)
CPU support
QDSP-6000 : Intel® Haswell ULT Core™ i3-4010U Processor
QDSP-6001 : Intel® Haswell ULT Core™ i5-4300U Processor
QDSP-6004 : Intel® Broadwell ULT Core™ i5-5350U Processor
QDSP-6006 : Intel® Broadwell ULT Celeron® 3765U Processor
QDSP-6007 : Intel® Haswell ULT Core™ i7-4650U Processor
QDSP-6008 : Intel® Broadwell ULT Core™ i7-5650U Processor
Memory
2x DDR3/L SO-DIMM up to 16GB
BIOS
AMI Plug & Play SPI BIOS
Storage
1x SATA connector for HDD/SSD support
1x eSATA connector with power supply
1x mSATA socket
Front IO
ˍġ Realtek ALC662 HD Codec w/ 2W Audio Amplifier, Mic-In, Line-In, Line-Out
ˍġ 1x S/PDIF Output
ˍġ 1x eSATA
ˍġ 2x USB 3.0
ˍġ 2x USB 2.0
ˍġ 1x Power Button with Power LED
ˍġ 1x Storage HDD status LED ( RED )
ˍġ 1x Wifi /3G status LED ( Green )
ˍġ 1x Reset Button
Rear IO
ˍġ 1x Lockable DC JACK
ˍġ 2x HDMI
ˍġ 2x USB3.0
ˍġ 2x RJ-45 GbE ports (Realtek RTL8111E/ Intel 82579 ) PXE / WOL supported
ˍġ 2x COM Ports support RS-232/422/485
ˍġ 2x WiFi External Antennas ( optional )
ˍġ 1x 3G External Antenna ( optional )
ˍġ 1x External Power Button
Expansion Slot
2x Mini-PCIe slots (1x SIM card holder supported)
TPM / iAMT
QDSP-6001/6004/6007/6008: TPM, iAMT supported
OS Support
Windows 7/Windows 8/ Linux
Hardware Monitor
Operating voltage, CPU temperature
Watchdog Timer
1-255 step, can be set with software on Super I/O
Power
Input: 100-240 VAC, 50-60 Hz
