Chapter 3
Table 9 Advanced Menu – Super IO Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Server Mgmt Save & Exit
Super IO Configuration
>Serial Port 1 Configuration
>Serial Port 2 Configuration
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Table 10 Advanced Menu –Super IO Configuration – Serial Port 1 Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Server Mgmt Save & Exit
Serial Port 1 Configuration ÆÅSelect Screen
ĹĻ6HOHFW,WHP
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4
Change Settings [Auto]
Serial Port 1 Type [RS232]
Version 2.15.1234. Copyright (C) 2012, American Megatrends, Inc.
Serial Port
Options: Disabled, Enabled
Change Settings
Options: Auto,
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
Serial Port 1 Type
Options: RS232, RS422, RS485
