Rev. 18-06-2010
P - 4
PP
PP
P
SERVICE MANUAL
532 / 577 nm 660 / 810 nm
The system is intended for continuous operation and has the following
classification:
- Protective class: I
(Main insulation)
- Type: BF (Protection against electrical schocks)
- Protection degree: IP20 (Protection from solid substances Ø>12,5mm)
- Operation: Continuous with short-time loading
WARNINGS:
HAZARD VOLTAGE PRESENCE INSIDE THE UNIT
- Laser power could be accessible upon removal of console cover:
DO NOT remove cover unless instructed to do so by a factory-trained
technician.
- Anyone in room during service or maintenance shall wear
protective safety goggles.
IMPORTANT: check carefully these protective glasses are adequate for the
wavelength used.
For the SUPRA range:
Protection OD4 at 532 nm: Reference (EN207): D 180-532 L4.
Protection OD4 at 577 nm: Reference (EN207): D 570-620 L4.
Protection OD4 at 660 nm: Reference (EN207): DIR 664 L4.
Protection OD4 at 810 nm: Reference (EN207): D 790-910 L4.
CAUTION: Use of controls or adjustments or performances other than those
specified herein may result in hazardous radiation exposure.
WARNINGS
TREATMENT BEAM AIMING BEAM
WAVELENGTH POWER WAVELENGTH POWER
532 nm up to 3,5 W
577 nm up to 2,2 W
660 nm up to 1,2 W 635 nm up to 1,2mW
810 nm up to 4 W
