Rev. 18-06-2010
P - 3
SERVICE MANUAL
532 / 577 nm 660 / 810 nm
WARRANTY: - Any adjusting and calibrating procedure described in this manual
shall be performed only by technicians previously trained by
QUANTEL MEDICAL.
- Any faulty part will be replaced by a strictly identical one provided by
QUANTEL MEDICAL.
- For safety reasons, QUANTEL MEDICAL considers any laser module
and electronic board as whole partial assembly:
* Defective boards will be returned to QUANTEL MEDICAL for
replacement.
* Warranty will not be applied if a board has been damaged
during an intervention or attempt to repair.
* The laser partial assemblies are:
"POWER SUPPLY block", "CPU Board",
"POWER Board", "OPTION POWER Board",
"I/O board" ,
"532 nm CAVITY block", "INJECTION Board".
"810 nm CAVITY block", or "660 nm CAVITY block"
"577 nm CAVITY block", "577 nm INTERFACE board".
Warranty will not be applied unless these recommendations are
strictly respected.
WARRANTY VOID
IF THE CAVITY IS OPENED
WARNINGS
CAUTIONS: All technicians will carefully respect all the safety instructions described
in this service manual.
WARNING: Special training by QUANTEL MEDICAL for technicians is necessary
to ensure optimum adjustment and maximum reliability of the whole
instrument.
LASER SAFETIES:
All staff using this laser system, or in charge of its maintenance, must
be aware of the following basic precautions to be taken:
1- Never look straight to the beam or to any reflecting object able
to reflect the beam.
2- Limit the laser room access to the requested personnel only,
who is already aware of precautions to be taken.
3- The laser room must be indicated with the specially designed
labels.
4- Never direct the laser beam towards an aperture.
5- Never expose any reflective object or shiny surface to the direct
beam path.
IMPORTANT: After each use, switch off the instrument completly by turning the
key to 'OFF' position.
