980 HDMI Protocol Analyzer Application Guide – Source Compliance Test Automation Rev. A1
Page 22 Feb 14, 2013
p-scope> pcap mode tmds // capture the raw TMDS data.
Pre-Capture Filter set to: RAW TMDS CHARACTERS
p-scope> pcap trig vsync 0 // sets the capture trigger to vsync.
Cap_trig: trigger basic type=0x1 position=0%
p-scope> pcap start // 980 initiates capture.
Waiting for the capture trigger event to occur…
(Vsync Asserted)
INFO: Capture Trigger condition is satisfied
END: pcap_capture_start Capture complete
Capturing data…
Post-Capture Processing (TMDS Phase)
p-scope> pcap cts d // run compliance test in detail mode
END: cts request complete
Analyzing the captured test data.
p-scope> exec perl /qd/hdmi_cts/HDMI_CTS.pl –f /home/qd –v 4 –t 7_17 –r 2
// run the 7-17 compliance test on the captured files.
Analyzing the captured test data.
Test 7-17 Iter 02 -> Pass
3.4.2 Video Pixel Encoding RGB – Test ID 7-23 Example
The following sequence of commands are used to run the 7-23 test.
Initialization
p-scope> hdmitx disable // disables the 980 HDMI Protocol Analyzer Tx port.
p-scope> slink down // disables the Encrypted Link Analyzer mode.
p-scope> mon hdmi // configuring the 980 for HDMI (rather than DVI).
p-scope> hp // toggle hot plug to cause an EDID read by the source.
Asserting 1sec HP pulse
Note: The Automated Test System now has to put the source device into the proper video and audio mode (i.e.
resolution, colorimetry, audio format etc.). If you are certain that the source is in the proper mode executing the
following command (vinfo) is optional. Otherwise the Automated Test System would have to parse out the
command response and issue a notification to the operator.
p-scope> vinfo // verify incoming video parameters.
HDMI RX Video Information:
HDMI Source +5V Power Signal: OK
HDMI Source SCDT Signal: OK
