980 HDMI Protocol Analyzer Application Guide – Source Compliance Test Automation Rev. A1
Page 27 Feb 14, 2013
Capture complete
Capturing data…
END: Capture complete, capture size 116.17MB [circular], buffer size 116.17MB
Post-Capture Processing
p-scope> pcap timing // generating field timing information.
END: pcap_info info request type=112 complete
p-scope> pcap decode // decode the captured data.
END: decode request complete
Indexing the decode data…
p-scope> pcap index // indexing the decoded data.
Analyzing the captured test data.
p-scope> exec perl /qd/hdmi_cts/HDMI_CTS.pl –f /home/qd –v 4 –t 7_29 –r 2
// run the 7-29 compliance test on the captured files.
Analyzing the captured test data.
Test 7-29 Iter 02 -> Pass
3.4.4 4K Video Resolution – Test ID 7-39 Example
The following sequence of commands are used to run the 7-39 test.
Initialization
p-scope> hdmitx disable // disables the 980 HDMI Protocol Analyzer Tx port.
p-scope> slink down // disables the Encrypted Link Analyzer mode.
p-scope> mon hdmi // configuring the 980 for HDMI (rather than DVI).
p-scope> hp // toggle hot plug to cause an EDID read by the source.
Asserting 1sec HP pulse
Note: The Automated Test System now has to put the source device into the proper video and audio mode (i.e.
resolution, colorimetry, audio format etc.). If you are certain that the source is in the proper mode executing the
following command (vinfo) is optional. Otherwise the Automated Test System would have to parse out the
command response and issue a notification to the operator.
p-scope> vinfo // verify incoming video parameters.
HDMI RX Video Information:
HDMI Source +5V Power Signal: OK
HDMI Source SCDT Signal: OK
.
.
.
