980 HDMI Protocol Analyzer Application Guide – Source Compliance Test Automation Rev. A1
Page 26 Feb 14, 2013
Test ID
% of full buffer (2GB)
Resulting/Required buffer size
7-16 – Legal Codes
41.492
743MB
7-17 – Protocol Test
41.492
743MB
7-18 – Extended Control Period
41.492
743MB
7-19 – Packet Types
41.492
743MB
7-21 – Minimum Format Support
6.483
116.17MB
7-22 – Additional Format Support
6.483
116.17MB
7-23 – Pixel Encoding RGB
6.483
116.17MB
7-24 – Pixel Encoding YcbCr
6.483
116.17MB
7-25 – Video Format Timing
6.483
116.17MB
7-26 – Pixel Repetition
6.483
116.17MB
7-27 – AVI Infoframe
6.483
116.17MB
7-28 – IEC 60958 / 61937
2.360
42MB
7-29 – ACR
22.654
405MB
7-30 – Audio Sample Packet Jitter
15.103
270MB
7-31 – Audio Infoframe
1.573
28MB
7-32 – Audio Sample Packet Layout
1.573
28MB
7-33 – Interoperability with DVI
2.360
42MB
7-34 – Deep Color
2.360
42MB
7-35 – Gamut Metadata Transmission
2.360
42MB
7-36 – High Bitrate Audio
41.492
743MB
7-37 – One Bit Audio
4.48
88MB
7-38 – 3D Video Format Timing
4.322
77MB
7-39 – 4K x 2K Video Format Timing
4.322
77MB
7-40 – Extended Colorimetry Transmission
4.322
77MB
p-scope> pcap mode all // captures all data types (video, data islands)
Pre-Capture Filter set to: No filtering
p-scope> pcap trig vsync 0 // sets the capture trigger to vsync
cap_trig: trigger basic type=0x1 position=0%
p-scope> pcap start // 980 initiates capture
Waiting for the capture trigger event to occur…
Vsync Asserted
INFO: Capture Trigger condition is satisfied
END: pcap_capture_start
