980 HDMI Protocol Analyzer Application Guide – Source Compliance Test Automation Rev. A1
Page 35 Feb 14, 2013
- bit values for 6 and 7 pertain to MHL only.
-p is a parameter that pertains to HDCP and is only used for the 980 GUI Manager and not used for Automated
Test Systems.
-q is a parameter that when set to 0 indicates that only a quick test is performed on tests 7-16, 7-17 & 7-18 and no
detailed analysis of any failures is conducted. A value of 1 indicates that detailed analysis will be performed.
The default is 0.
-r is a parameter that allows you to specify the version of the HDMI specification. Enter 1 for 1.4a and 2 for 1.3b1.
-s is a parameter that specifies the sampling rate of the incoming audio in kHz. This could be for example 48,
44.1, 96, etc.
-t is a parameter that provides the CTS Test ID (s) to be run. If no –t argument is provided the script will run all
HDMI source tests. In the example above, only the 7-17 test will be run.
-v is a parameter provides the CEA Video Identification Code (VIC) for the format resolution being tested. If using
a non CEA format, use 0 as the value of this parameter.
