Quantum DXi6802 and DXi690x: Rack Mount Rails Replacement
6-68446-01
April 2016
Replacing the DXi6802 or DXi690x Node Rails 3
Replacing the DXi6802 or DXi690x Node Rails
Follow the steps below to replace the DXi6802 or DXi690x Node rails:
1 Removing the DXi6802 or DXi690x Node from the Rack on page 3
2 Installing the DXi6802 or DXi690x Node Rack Mounting Rails on page 5
3 Installing the DXi6802 or DXi690x Node on page 6
Removing the DXi6802
or DXi690x Node from
the Rack
To remove the DXi6802 or DXi690x Node from the rack:
1 Shut down the DXi6802 or DXi690x system (see Shutting Down the System
on page 2).
2 If installed, remove the front bezel from the Node by lifting the latch on the
left side of the bezel.
3 Remove all power, SAS, Ethernet, and Fibre Channel cables from the rear of
the Node. Make sure to label the cables so they can be easily identified
when they are re-connected to the Node after the replacement procedure is
complete.
4 Press the locking tab on either side of the Node, and slide the Node out
from the rack until the inner rails lock.
Note: If necessary, remove the optional screws securing the Node to the
front of the rack (behind the locking tab).
5 Locate the lock levers on the sides of the inner rails (see Figure 3). Unlock
each lever by rotating it up to its release position.
