12 Replacing the DXi690x Array or Expansion Module Rails
Replacing the DXi690x Array or Expansion Module Rails
Note: NetApp Co-Branded EMEA installations do not follow the rack
installation procedures below. NetApp Co-Branded EMEA Array and
Expansion Module rails follow the same procedures as the DXi6802
disk backup system (see
Replacing the DXi6802 Array or Expansion
Module Rails on page 8).
Follow the steps below to replace the DXi690x Array or Expansion Module rails:
1 Removing the DXi690x Array or Expansion Module from the Rack on
page 12
2 Installing the DXi690x Array or Expansion Module Rack Mounting Rails on
page 15
3 Installing the DXi690x Array or Expansion Module on page 16
Removing the DXi690x
Array or Expansion
Module from the Rack
To remove the DXi690x Array or Expansion Module from the rack:
1 Shut down the DXi690x system (see Shutting Down the System on page 2).
2 Remove all power and SAS cables from the rear of the Array or Expansion
Module. Make sure to label the cables so they can be easily identified when
they are re-connected to the module after the replacement procedure is
complete.
3 Remove the end caps from each side of the Array or Expansion Module.
4 Remove the 10-32 x 3/4 in. SEM screw with washer on each side of the Array
or Expansion Module’s front panel (see
Figure 11).
