On/Off Button
Enables/disables power
Mode Button
Cycle through Drive Profiles and Seat Mode (if equipped)
Battery Condition Meter
Indicates battery charge
Actuator LEDs
Indicates actuators in use
Mode LED
Used for profile selection
Joystick
They joystick controls speed and direction in Drive mode. Push the joystick to the right to select
actuators in Seat mode. Move the joystick forward or backward to activate the desired actuator(s).
On/Off and Mode Jacks
Allow for remote On/Off and Mode switch installations
Standby Select Menu
The Standby Select Menu screen appears after the programmed timeout when Standby Select is
enabled. Standby Select will navigate the Home Screen allowing the user to access the drive, seat or
settings screen, Contact your Quantum Rehab Provider for more information.
Attendant Control and Standalone Joystick
For more information on these applications, contact your Quantum Rehab Provider.
The Attendant Control and the Stand-alone Joystick are similarly laid out:
