Quantum Q-Logic 3 User Manual


Error
Code
Popup
Text
Description
(programming device)
Help text
(programming device)
1 Motor 1 not
connected
Error: Motor 1 not connected Motor 1 error detected
1. Turn power off
2. Inspect motor connections
3. Turn power on
2 Motor 2 not
connected
Defect: Motor 2 not connected Motor 2 error detected
1. Turn power off
2. Inspect motor connections
3. Turn power on
3
Brake 1 not
connected
Error: Brake 1 not connected Brake 1 error detected
1. Turn power off
2. Disengage then re-engage brake lever
3. Inspect motor connections
4. Turn power off
4
Brake 2 not
connected
Error: Brake 2 not connected Brake 2 error detected
1. Turn power off
2. Disengage then re-engage brake lever
3. Inspect motor connections
4. Turn power off
20 Undervoltage Error: Undervoltage Charge Battery
21 Overvoltage Error: Overvoltage Check the battery voltage, batteries may be
overcharged. Avoid driving downhill fast with fully
charged batteries.
23 Motor 1 output
defect
Error: Motor 1 output defect Motor 1 error detected
1. Turn power off
2. Inspect motor connections
3. Turn power on
24 Motor 2 output
defect
Error: Motor 2 output defect Motor 2 error detected
1. Turn power off
2. Inspect motor connections
3. Turn power on
25 Brake 1 error Error: Brake 1 error Brake 1 error detected
1. Turn power off
2. Disengage then re-engage brake lever
3. Inspect motor connections
4. Turn power on
26 Brake 2 error Error: Brake 2 error Brake 2 error detected
1. Turn power off
2. Disengage then re-engage brake lever
3. Inspect motor connections
4. Turn power on
32 Speed reduction
(Overtemperature)
Error: Speed reduction
(Overtemperature)
Chair speed is reduced to protect sy stem
electronics
1. Turn power off to let system cool down.
NOTE: This is the normal system behavior
34 Joystick not centered Error: Joystick not centered Joystick deflected at power up
1. Turn power off
2. Release joystick to neutral position
3. Turn power on
35 Joystick out of center Defect: Joystick out of center Joystick deflected at power up
1. Turn power off
2. Release joystick to neutral position
3. Turn power on
