QXS-324/424 12G System Specifications 21
Chapter 3
QXS-324/424 12G System Specifications
This chapter provides the following information:
• QXS-324/424 12G: 2U24-Drive RAID and Expansion Chassis
• QXS-324/424 12G RAID and Expansion Physical Requirements
• QXS-324/424 12G RAID and Expansion Chassis Dimensions
• QXS-324/424 12G RAID and Expansion Rackmount Chassis Weights
QXS-324/424 12G: 2U24-Drive RAID and Expansion Chassis
This section provides 2U24-drive RAID and expansion chassis system component/CRU information.
The front of the QXS-324 12G and QXS-424 12G look the same.
2U24-Drive Chassis
Figure 21 provides a front view of the 2U24-drive chassis. Chassis is shipped with drives installed.
Figure 21 2U24-Drive Chassis
The 2U24 chassis can be configured as a RAID chassis or an expansion chassis.
