Environment and Requirements 47
QXS 2U PSU (580W) Specifications
Tab l e 22 provides the 2U PSU (580W) specifications.
QXS 5U PSU (2114W) Specifications
Tab l e 23 provides the 5U PSU (2114W) specifications.
Ta bl e 2 2 QXS 2U PSU (580W) Specifications
Specification Measurement/Description
Dimensions (size) 84.3 mm high x 104.5 mm wide x 340.8 mm long:
• X-axis length: 104.5 mm (4.11 in)
• Y-axis length: 84.3 mm (3.32 in)
• Z-axis length: 340.8 mm (37.03)
Maximum output power 580W
Voltage range 100–200 VAC rated
Frequency 50-60 Hz
Voltage range selection Auto-ranging: 90–264 VAC, 47–63 Hz
Power factor correction ³ 95% @ nominal input voltage
Efficiency 115 VAC/60 Hz 230 VAC/50 Hz
> 80% @ 10% load
> 87% @ 20% load
> 90% @ 50% load
> 87% @ 100% load
> 85% @ surge
> 80% @ 10% load
> 88% @ 20% load
> 92% @ 50% load
> 88% @ 100% load
> 85% @ surge
Harmonics Meets EN61000-3-2
Output +5 V @ 42A, +12 V @ 38A, +5 V standby voltage @ 2.7A
Operating temperature 0 to 57ºC (32ºF to +135ºF)
Hot pluggable Yes
Switches and LEDs AC mains switch and four status indicator LEDs
Chassis cooling Dual axial cooling fans with variable fan speed control
Ta bl e 2 3 QXS 5U PSU (2114W) Specifications
Specification Measurement/Description
Maximum output power 2214W maximum continuous output power at high line voltage
Voltage +12 V at 183 A (2,196 W)
+5 V standby voltage at 2.7 A
Voltage range 200–240 VAC rated
Frequency 50-60 Hz
Power factor correction >/= 95% @ 100% load
