Quantum Scalar i40 Replacement Manual

Quantum Scalar i40 and Scalar i80: Tape Drive Replacement
6-66561-02 Rev B
February 2014
Replacing a Tape Drive with a Filler Plate 7
Replacing a Tape Drive with a Filler Plate
The filler plate is half-height in size. If you remove a full-height tape drive, you
must install two filler plates to cover the opening.
1 The tape drive filler plate has no “top” or “bottom” orientation – it can go in
either way (see
Figure 3 on page 7).
2 Slide the filler plate into the slot, and tighten the thumbscrews.
Figure 3 Tape Drive Filler Plate
Tape Drive Filler
Plate
Captive thumbscrews

Quantum Scalar i40 Specifications

General

Power requirements	100 - 240 V AC, 50 - 60 Hz, 2.8/1.4 Amps
Power consumption (typical)	100 W
Expansion slots	25
Dimensions (WxDxH)	455 x 793 x 132 mm
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Media type	Tape Cartridge
Product type	Storage auto loader & library
Product color	Black

Weight and Dimensions

Weight	15800 g
