Connecting and Securing the Power Rails
The power rails are pre-installed. You need to secure adjacent power rails using bridge clamps and connect
adjacent rails via their connectors.
Required tools: 2.5 mm hex wrench
Required equipment:
• Two bridge clamps per pair of adjacent power rails
• Screw A, M4X10 socket head cap screws (low profile) — 2 per bridge clamp
1 Secure adjacent power rails together with two bridge clamps, one on the upper edge of the rails and
one on the lower edge of the rails. Use the screw holes available on the power rails. Use a 2.5 mm hex
wrench to install two screws in each bridge clamp. See Figure 1
on 14.
2 Connect the power connectors on all adjacent power rails. There are two power connectors on each
side of each rail — a 4-pin connector and a 3-pin connector. The right-most connectors in the right
parking module will not have anything plugged into them. See Figure 2
on 15.
