4 Installing and Configuring the SKM Appliance Servers
Quantum Scalar Key Manager 2.5 Quick Start Guide
Figure 1 SKM Appliance Server
Rear Panel
The rear of your server looks like one of the drawings below.
4 Observe the power-on LED on the front panel (see Figure 2). Wait until the power-on
LED blinks slowly to indicate that the power button is active.
If the power-on LED is not blinking, there could be a problem with the power supply
or the LED. Check the power connection. If this LED still does not blink, contact
Quantum Support.
Power cord
connector
Ethernet Port 1
(configuration)
Ethernet Port 2
(network)
Power cord
connector
Ethernet Port 1
(configuration)
Ethernet Port 2
(network)
M2 and earlier
M3 and M4
Power cord
connector
Ethernet Port 1
(configuration)
Ethernet Port 2
(network)
M5
Power cord
connector
Ethernet Port 2
(network)
Ethernet Port 1
(configuration)
M6
