QF1200S; edition 2016-05; page 24 of 24
Description Unit
QF1200S
Standard Motor
QF1200S
Synchronmotor
QF1200S - CV
Integrated
Controller
QF1200S
Synchronmotor
Custom tarif number 84138100 84138100 84138100 84138100
Certificates/proofs (optional):
Elastomere (product wetted)
USP <88> Cl. VI;
FDA21CFR177;
BSE/TSE Safe
USP <88> Cl.
VI;
FDA21CFR177;
BSE/TSE Safe
USP <88> Cl.
VI;
FDA21CFR177;
BSE/TSE Safe
USP <88> Cl.
VI;
FDA21CFR177;
BSE/TSE Safe
Stainless steel parts (product wetted)
3.1; Surface
roughness; Ferrite
content
3.1; Surface
roughness;
Ferrite content
3.1; Surface
roughness;
Ferrite content
3.1; Surface
roughness;
Ferrite content
Motor/Gear:
Manufacturer (standard) EMK or Behnke Engel Panasonic Engel
Type KAE1A71B
HBI37904A
3000/4000
MBMS082BL
HBI37904A
3000/4000
Rated speed min-1 1375 (50 Hz) 3000 2200 3000
Voltage V 230/400 48 VDC 230 48 VDC
Ampacity A 1,85/1,06 13,5 4 13,5
Power KW 0,37 0,485 0,75 0,485
Shaft diameter mm 14 14 14 14
Color RAL 5010/7031 grey/silver grey/silver grey/silver
Forced ventilation in hood yes yes yes yes
Coupling KTR (Rotex) KTR (Rotex) KTR (Rotex) KTR (Rotex)
Gear ratio n/a n/a n/a n/a
Additional information controller: Optional Optional Standard Standard
Type
Frequency Converter;
integrated into
separate Control Box
Power Supply
Unit
(separate)
Controller
(integrated in
pump)
Power Supply
Unit (integrated
in pump)
Manufacturer (standard) Lenze/ AC-tech
TDK Lambda
(power supply)
Panasonic Mean Well
Designation SMVector; 0.37kW HWS MBEK083BCV HRPG-600-48
Analog input (optional) 4-20 mA oder 0-10 V 0-10 V 0-5 V
4-20mA
(standard)
Protection class IP54
IP20
(for installation
into electr.
cabinet)
see pump
housing
see pump
housing
Power supply
230V, 50Hz, 1P; or
110V/60 Hz; 1P
85 - 265VAC
50/60 Hz; 8,2 A
200-240V, 50/60
Hz, 1P
100-240V; 8,5A
Housing material SS304 n/a
see pump
housing
see pump
housing
Dimensions (length x width x height)
mm
(inch)
350 x 155 x 210
(13.78 x 6.10 x 8.27)
100 x 82 x 165
(3.94 x 14.96 x
15.35)
see pump
housing
see pump
housing
Weight approx. kg (lb) 8 (17.64) 1,6 (3.53) - -
All technical data relate to a Quattroflow pump in the standard version. Special designed pumps (e.g.
special product connections) may have different data that can be found in the advanced
documentation for each Quattroflow pump.
Quattroflow is a brand of ALMATEC Maschinenbau GmbH.
ALMATEC is constantly working on improvements of the pump. Modifications of the design or materials might be done without
prior notice.
Subject to change without notice, 2016-05
ALMATEC Maschinenbau GmbH
Carl-Friedrich-Gauss-Str. 5 · D-47475 Kamp-Lintfort, Germany
Telephone +49 (0) 2842 961-0 · Fax +49 (0) 2842 961-40
www.quattroflow.com · info@almatec.de
