7. Technical data of the QF 1200S
Description Unit
QF1200S
Standard Motor
QF1200S
Synchronmotor
QF1200S - CV
Integrated
Controller
QF1200S - HT
Integrated
Controller
Flow rate max.:
Eccentric shaft 3° l/h (gph) 800 (211) - - -
Eccentric shaft 5° l/h (gph) 1200 (317) 1200 (317) 1200 (317) 1200 (317)
Flow rate min.:
Eccentric shaft 3° l/h (gph)
10 (2.64) [appr. 20 (5.28)
with separate controlbox]
- - -
Eccentric shaft 5° l/h (gph)
20 (5,3) [appr. 40 (10.6)
with separate controlbox]
6 (1.6) 10 (2.64) 6 (1.6)
Pressure:
Temperature of fluid < 40°C bar (psi) 6 (87) 6 (87) 6 (87) 6 (87)
Temperature of fluid > 40°C bar (psi) 4 (58) 4 (58) 4 (58) 4 (58)
Temperature max.:
Fluid °C (°F) 80 (176) 80 (176) 80 (176) 80 (176)
CIP °C (°F) 90 (194) 90 (194) 90 (194) 90 (194)
SIP °C (°F) 130 (260) 130 (260) 130 (260) 130 (260)
Autoclave °C (°F) 130 (260) 130 (260) 130 (260) 130 (260)
Suction lift dry at: 1800rpm 1800rpm 1800rpm 1800rpm
Eccentric shaft 3° m (ft) 2,5-3 (8.2-9.8) - - -
Eccentric shaft 5° m (ft) 4-4,5 (13.1-14.7) 4-4,5 (13.1-14.7) 4-4,5 (13.1-14.7) 4-4,5 (13.1-14.7)
Volume specifications:
Approximated volume per revolution
at free output
ml
9,6 (5°)
5,8 (3°)
9,6 9,6 9,6
Filling volume without connectors ml 75 75 75 75
Residual volume (after idle with high-
speed motor)
ml
ca. 8-26; depends on
installation position
ca. 8-26;
depends on inst.
position
ca. 8-26;
depends on inst.
position
ca. 8-26;
depends on inst.
position
Product wetted surface (approx.) cm² (inch²) 367 (57) 367 (57) 367 (57) 367 (57)
Speed range pump rpm 30-2400 10-2400 10-2200 10-2400
Connection specification inlet (std)
Connector " 3/4" TC 3/4" TC 3/4" TC 3/4" TC
Flange diameter mm (inch) 25 25 25 25
Internal diameter mm (inch) 15,75 15,75 15,75 15,75
Connection specification outlet
(standard)
Connector " 3/4" TC 3/4" TC 3/4" TC 3/4" TC
Flange diameter mm 25 25 25 25
Internal diameter mm (inch) 15,75 (0.62) 15,75 (0.62) 15,75 (0.62) 15,75 (0.62)
Position of connectors Inline Inline Inline Inline
Number of flow directions 4 4 4 4
Diameter drive shaft mm 14 14 14 14
Product wetted materials (std.):
Pump housing SS316L SS316L SS316L SS316L
Valve plate SS316L SS316L SS316L SS316L
Diaphragms TPE TPE TPE TPE
Valves EPDM EPDM EPDM EPDM
O-rings EPDM EPDM EPDM EPDM
Non-product wetted materials (std):
Membrane cover SS316L SS316L SS316L SS316L
Bearing housing SS316L SS316L SS316L SS316L
Base plate SS316 SS316 SS316 SS316
Hood SS316 SS316 SS316 SS316
Dimensions pump with motor and
housing:
Length mm (inch) 487 (19.17) 487 (19.17) 487 (19.17) 523 (20.59)
Width mm (inch) 159 (6.26) 159 (6.26) 200 (7.87) 200 (7.87)
Height mm (inch) 210 (8.27) 210 (8.27) 210 (8.27) 220 (8.66)
Weight pump: kg (lb) 24 (53) 25 (55) 25 (55) 25 (55)
IP protection class IP IP54 IP54 IP54 IP54
