QUBINO Smart meter User Manual

EN.
30
MEASUREMENTS:
V
Voltage
A
Current
W
Power – Active
var
Power – Reactive
PF
Power Factor
kWh
Energy – Active power accumulated Import
kWh
Energy – Active power accumulated Export
kVAh
Energy – Apparent power accumulated
kvarh
Energy – Reactive power accumulated
DIMENSIONAL DRAWING:

QUBINO Smart meter Specifications

General

Communication Protocol	Z-Wave
Weight	150 g
Rated Current	65 A
Accuracy	Class 1
Frequency	50/60 Hz
Radio Protocol	Z-Wave
Power Consumption	< 1 W
Z-Wave Frequency	868.42 MHz (EU)
Range	Up to 30 m indoors
Operating Temperature	-10°C to +40°C
