QUBINO Smart meter User Manual

EN.
44
14. Technical Specifications
Main terminals (LI, NI, Lo, No)
Contacts capacity:
1.5 ... 16 (25) mm2
Connection screws:
M5
Max torque:
3.5 Nm (PZ2)
Optional terminals (1,2,4,5)
Contact capacity:
0.05 ... 1 (2.5) mm2
Screws:
M3
Max torque:
0.6 Nm
Measuring input:
Type (connection):
single phase (1b)
Reference current (Iref):
5 A
Maximum current (Imax):
65 A
Minimum current (Imin):
0.25 A
Starting current:
20 mA
Voltage (Un):
230 V (±20 %)
Power consumption at Un:
< 2W
Nominal frequency (fn):
50 and 60 Hz
Accuracy:
Active energy and power:
Standard EN 62053-21:
class 1
Standard EN 50470-3:
class B
Reactive energy:
Standard EN 62053-23:
class 2
Optical communication:
Type:
IR - used to control BICOM432-40-WM1
Input (1):
Rated voltage:
230 V (± 20%)

QUBINO Smart meter Specifications

General

Communication Protocol	Z-Wave
Weight	150 g
Rated Current	65 A
Accuracy	Class 1
Frequency	50/60 Hz
Radio Protocol	Z-Wave
Power Consumption	< 1 W
Z-Wave Frequency	868.42 MHz (EU)
Range	Up to 30 m indoors
Operating Temperature	-10°C to +40°C
