QUBINO Smart meter User Manual

EN.
43
Parameter no. 112 - Relay to power off
Set value selects relay to be powered off when threshold is reached (defined by parameters no.
110 and 111).
Values (size is 1 byte dec):
 default value 0
 0 - switch between the 2 relays (power off relay 1 first, after power on, if power
consumption is still over, power off relay 2, ...)
 1 - always power off relay 1 (IR external relay)
 2 - always power off relay 2 (External relay)
 3 - always power off both relays (relay 1 and relay 2)
Parameter no. 130 – Serial Number
Read only. Unsigned Value (32bit)

QUBINO Smart meter Specifications

General

Communication Protocol	Z-Wave
Weight	150 g
Rated Current	65 A
Accuracy	Class 1
Frequency	50/60 Hz
Radio Protocol	Z-Wave
Power Consumption	< 1 W
Z-Wave Frequency	868.42 MHz (EU)
Range	Up to 30 m indoors
Operating Temperature	-10°C to +40°C
