QUBINO Smart meter User Manual

EN.
45
Input resistance:
450 kOhm
Safety:
Indoor Meter:
yes
Degree of pollution:
2
Protection class:
II
AC voltage test:
4 kV
Installation Category:
300 Vrms cat. III
Standard:
EN 50470
Ambient conditions and EMC:
According standards for indoor active energy Meters.
Temperature and climatic condition according to EN 62052 11
Ambient conditions and Safety:
According standards for indoor active energy Meters.
Temperature and climatic condition according to EN 62052 11
Dust/water protection:
IP20
Operating temperature:
-15 ... 55°C
Storage temperature:
-40 ... 70°C
Enclosure material:
Self-extinguish
complying UL94 V
Indoor Meter:
yes
Degree of pollution:
2
AC voltage test:
4 kV
Distance:
up to 30 m indoors (depending on building materials)
Weight (with packaging):
150g (170g)
Frequency range:
868.4 MHz, Z-Wave
Installation
Din rail 35mm
Dimensions (W x H x D):
36 x 90 x 64mm
Package dimensions (W x H x D):
40 x 95 x 80mm
Colour
RAL 7035

QUBINO Smart meter Specifications

General

Communication Protocol	Z-Wave
Weight	150 g
Rated Current	65 A
Accuracy	Class 1
Frequency	50/60 Hz
Radio Protocol	Z-Wave
Power Consumption	< 1 W
Z-Wave Frequency	868.42 MHz (EU)
Range	Up to 30 m indoors
Operating Temperature	-10°C to +40°C
