11 Appendix D EDGE Modulation and
Coding Schemes
Table 49: EDGE Modulation and Coding Schemes
Coding Scheme Modulation Coding Family Timeslot 1 Timeslot 2 Timeslot 4
MCS-1 GMSK C 8.80 kbps 17.60 kbps 35.20 kbps
MCS-2 GMSK B 11.2 kbps 22.4 kbps 44.8 kbps
MCS-3 GMSK A 14.8 kbps 29.6 kbps 59.2 kbps
MCS-4 GMSK C 17.6 kbps 35.2 kbps 70.4 kbps
MCS-5 8-PSK B 22.4 kbps 44.8 kbps 89.6 kbps
MCS-6 8-PSK A 29.6 kbps 59.2 kbps 118.4 kbps
MCS-7 8-PSK B 44.8 kbps 89.6 kbps 179.2 kbps
MCS-8 8-PSK A 54.4 kbps 108.8 kbps 217.6 kbps
MCS-9 8-PSK A 59.2 kbps 118.4 kbps 236.8 kbps
