Quectel EC200T Series

LTE Standard Module Series
EC200T Series Hardware Design
EC200T_Series_Hardware_Design 14 / 90
2 Product Concept
2.1. General Description
EC200T is a series of LTE-FDD, LTE-TDD, WCDMA and GSM wireless communication module with
receive diversity, which provides data connectivity on LTE-FDD, LTE-TDD, HSDPA, HSUPA, HSPA+,
WCDMA, EDGE and GPRS networks. It also provides voice functionality for your specific applications.
EC200T series contains 3 variants: EC200T-CN, EC200T-EU and EC200T-AU*. You can choose a
dedicated type based on the region or operator. The following table shows the frequency bands of
EC200T series module.
Table 1: Frequency Bands of EC200T-CN Module
Table 2: Frequency Bands of EC200T-EU Module
Network Type Bands
LTE-FDD (with Rx-diversity)
1)
B1/B3/B5/B8
LTE-TDD (with Rx-diversity)
1)
B34/B38/B39/B40/B41
WCDMA B1/B5/B8
GSM 900/1800MHz
Network Type Bands
LTE-FDD (with Rx-diversity)
1)
B1/B3/B7/B8/B20/B28
LTE-TDD (with Rx-diversity)
1)
B38/B40/B41
WCDMA B1/B8
GSM 900/1800MHz
