1.
1)
Within operating temperature range, the module is 3GPP compliant.
2.
2)
Within extended temperature range, the module remains the ability to establish and maintain a
voice, SMS, data transmission, etc. There is no unrecoverable malfunction. There are also no effects
on radio spectrum and no harm to radio network. Only one or more parameters like P
out
might reduce
in their value and exceed the specified tolerances. When the temperature returns to the normal
operating temperature levels, the module will meet 3GPP specifications again.
5.4. Current Consumption
The following table shows the current consumption of EC200T-CN.
Table 34: EC200T-CN Current Consumption
Parameter Description Conditions Typ. Unit
I
VBAT
OFF state Power down 11 uA
Sleep state
AT+CFUN=0 (USB disconnected)
1.67 mA
EGSM900 @ DRX = 2 (USB disconnected) 3.04 mA
EGSM900 @ DRX = 5 (USB disconnected) 1.94 mA
EGSM900 @ DRX = 5 (USB suspend) 2.11 mA
EGSM900 @ DRX = 9 (USB disconnected) 1.64 mA
DCS1800 @ DRX = 2 (USB disconnected) 3.01 mA
DCS1800 @ DRX = 5 (USB disconnected) 1.93 mA
DCS1800 @ DRX = 5 (USB suspend) 2.08 mA
DCS1800 @ DRX = 9 (USB disconnected) 1.61 mA
WCDMA @ PF = 64 (USB disconnected) 3.93 mA
WCDMA @ PF = 64 (USB suspend) 4.08 mA
WCDMA @ PF = 128 (USB disconnected) 2.70 mA
WCDMA @ PF = 256 (USB disconnected) 2.12 mA
NOTES
