LTE Standard Module Series
EC200T Series Hardware Design
EC200T_Series_Hardware_Design 45 / 90
MAIN_RTS 65 DI
Main UART request to
send
MAIN_DTR 66 DI
Main UART data
terminal ready
MAIN_TXD 67 DO Main UART transmit
MAIN_RXD 68 DI Main UART receive
Table 14: Pin Definition of Debug UART Interface
Pin Name Pin No. I/O Description Comment
DBG_RXD 11 DI Debug UART receive
1.8 V power domain.
If unused, keep it open.
DBG_TXD 12 DO Debug UART transmit
The logic levels are described in the following table.
Table 15: Logic Levels of Digital I/O
Parameter Min. Max. Unit
V
IL
-0.3 0.6 V
V
IH
1.2 2.0 V
V
OL
0 0.45 V
V
OH
1.35 1.8 V
The module provides a 1.8 V UART interface. A level translator should be used if the application is
equipped with a 3.3 V UART interface. A level translator TXS0108EPWR provided by Texas Instruments
is recommended. The following figure shows a reference design.
