LTE Standard Module Series
EC200T Series Hardware Design
EC200T_Series_Hardware_Design 71 / 90
GSM
voice call
EGSM900 PCL = 5 @ 32.27 dBm 242.2 mA
EGSM900 PCL = 12 @ 19.64 dBm 120.1 mA
EGSM900 PCL = 19 @ 5.75 dBm 94.2 mA
DCS1800 PCL = 0 @ 29.95 dBm 223.6 mA
DCS1800 PCL = 7 @ 16.27 dBm 116.2 mA
DCS1800 PCL = 15 @ 1.11 dBm 92.2 mA
WCDMA
voice call
WCDMA B1 @ 23.57 dBm 646.9 mA
WCDMA B5 @ 23.07 dBm 556.1 mA
WCDMA B8 @ 23.21 dBm 653.1 mA
“*” means under development.
Table 35：EC200T-EU Current Consumption
Parameter Description Conditions Typ. Unit
I
VBAT
OFF state Power down 11 uA
Sleep state
AT+CFUN=0（USB disconnected）
1.02 mA
EGSM900 @ DRX = 2（USB disconnected）
3.67 mA
EGSM900 @ DRX = 5（USB disconnected）
3.00 mA
EGSM900 @ DRX = 5（USB suspend）
3.15 mA
EGSM900 @ DRX = 9（USB disconnected）
3.47 mA
DCS1800 @ DRX = 2（USB disconnected）
3.55 mA
DCS1800 @ DRX = 5（USB disconnected）
3.24 mA
NOTE
